VirtualBox + Secure Boot + Ubuntu = fail

Here are the steps I did to enable VirtualBox to work properly in Ubuntu with UEFI Secure Boot fully enabled*. The problem is the requirement that all kernel modules must be signed by a key trusted by the UEFI system, otherwise loading will fail. Ubuntu does not sign the third party vbox* kernel modules, but rather gives the user the option to disable Secure Boot upon installation of the virtualbox package. I could do that, but then I would see an annoying “Booting in insecure mode” message every time the machine starts, and also the dual boot Windows 10 installation I have would not function.

*Ubuntu 16.04 on a Dell Latitude E7440 with BIOS A18, and with a dual boot Windows 10 installation.

Credit goes to the primary source of information I used to resolve this problem, which applies specifically to Fedora/Redhat:
http://gorka.eguileor.com/vbox-vmware-in-secureboot-linux-2016-update/

And a relevant Ask Ubuntu question:
http://askubuntu.com/questions/760671/could-not-load-vboxdrv-after-upgrade-to-ubuntu-16-04-and-i-want-to-keep-secur

Steps to make it work, specifically for Ubuntu/Debian

  1. Install the virtualbox package. If the installation detects that Secure Boot is enabled, you will be presented with the issue at hand and given the option to disable Secure Boot. Choose “No”.
  2. Create a personal public/private RSA key pair which will be used to sign kernel modules. I chose to use the root account and the directory /root/module-signing/ to store all things related to signing kernel modules.
    $ sudo -i
    # mkdir /root/module-signing
    # cd /root/module-signing
    # openssl req -new -x509 -newkey rsa:2048 -keyout MOK.priv -outform DER -out MOK.der -nodes -days 36500 -subj "/CN=YOUR_NAME/"
    [...]
    # chmod 600 MOK.priv
  3. Use the MOK (“Machine Owner Key”) utility to import the public key so that it can be trusted by the system. This is a two step process where the key is first imported, and then later must be enrolled when the machine is booted the next time. A simple password is good enough, as it is only for temporary use.
    # mokutil --import /root/module-signing/MOK.der
    input password:
    input password again:
  4. Reboot the machine. When the bootloader starts, the MOK manager EFI utility should automatically start. It will ask for parts of the password supplied in step 3. Choose to “Enroll MOK”, then you should see the key imported in step 3. Complete the enrollment steps, then continue with the boot. The Linux kernel will log the keys that are loaded, and you should be able to see your own key with the command: dmesg|grep 'EFI: Loaded cert'
  5. Using a signing utility shippped with the kernel build files, sign all the VirtualBox modules using the private MOK key generated in step 2. I put this in a small script /root/module-signing/sign-vbox-modules, so it can be easily run when new kernels are installed as part of regular updates:
    #!/bin/bash

    for modfile in $(dirname $(modinfo -n vboxdrv))/*.ko; do
      echo "Signing $modfile"
      /usr/src/linux-headers-$(uname -r)/scripts/sign-file sha256 \
                                    /root/module-signing/MOK.priv \
                                    /root/module-signing/MOK.der "$modfile"
    done

    # chmod 700 /root/module-signing/sign-vbox-modules
  6. Run the script from step 5 as root. You will need to run the signing script every time a new kernel update is installed, since this will cause a rebuild of the third party VirtualBox modules. Use the script only after the new kernel has been booted, since it relies on modinfo -n and uname -r to tell which kernel version to sign for.
  7. Load vboxdrv module and fire up VirtualBox:
    # modprobe vboxdrv

The procedure can also be used to sign other third party kernel modules, like the nvidia graphics drivers, if so is required. (I have not tested that myself.)

Gracefully killing a Java process managed by systemd

The basic way for systemd to stop a running service is by sending the SIGTERM signal (a regular kill) to the process control group of the service, and after a configurable timeout, a SIGKILL to make things really go away if not responding. Of course, all the details are configurable, and often times you’d have some sort of control script which did the actual stopping, but I am only talking about the simple case here. I have a Java-based service and a Unit configuration file to integrate it with systemd. The JVM process is setup so that it gracefully shuts down the service upon reception of the SIGTERM signal (using shutdown hooks). However, the JVM will still exit with code 143 in the end due to receiving SIGTERM (128+15), and systemd thinks something went wrong when stopping the service. The solution is simple: add SuccessExitStatus=143  to the Unit configuration file for the service, and systemd will consider this code as successful termination. If the graceful shutdown can take some time, add TimeoutStopSec=NN as well to give the service process more time before systemd brings out the big gun.

Relevant manual pages: systemd.kill and systemd.service.

Securing web site with https and Let’s Encrypt

A padlock imageI have added support for secure communication using https/TLS to my personal web site, which runs on Linux home servers using Apache. After Let’s Encrypt appeared and started offering free security certificates, there was really no reason not to give it a spin. And there are many good reasons to support secure http communication, even for sites not dealing with sensitive or secret information:

  • Data integrity. Using https is an effective way to prevent tampering with the data from the server to the client. It is not unheard of for ISPs or other third parties to modify http traffic, for instance to inject ads in pages, and https is an effective counter measure.
  • Initiatives like Mozilla’s “deprecation of non-secure HTTP”, which aims to move the web to secure communication by default.
  • Giving visitors the choice to keep their web browsing private across the internet.
  • Allow secure site administration.

Skip directly to a section in this post:

  1. Acquiring a Let’s Encrypt certificate
  2. Configuring Apache on Ubuntu 14.04 to use Let’s Encrypt certificate
  3. WordPress and https
  4. Validating https protocol support
  5. Automatic certificate renewal
  6. Donations to Let’s Encrypt and the way forward

Acquiring a Let’s Encrypt certificate

Using this recipe as a guide, I decided to use the certbot tool, which automates the process of verifying ownership of domain and downloading a new certificate from Let’s Encrypt. It also provides automation of the certificate renewal process, which is necessary with Let’s Encrypt due to rather short expiry periods.

As preparation, basic SSL support in Apache should be enabled. This is accomplished on a standard Debian/Ubuntu Apache by doing as super user:

cd /etc/apache2/mods-enabled/
ln -s ../mods-available/ssl.* ../mods-available/socache_shmcb.load .

/usr/sbin/apachectl graceful

This links up the required modules and default configuration, then reloads Apache config. Since certbot requires that your Apache server is reachable from the internet on port 443, make sure any required port forwardings and/or firewall rules are adjusted in your router.

Note that there is a default virtualhost configuration for SSL in the file /etc/apache2/sites-available/default-ssl.conf. However, there is no need to enable this file, as all the required SSL options are added to the name based virtualhost for the site. If you decide to link default-ssl.conf into /etc/apache2/sites-enabled/, you should edit it to include /etc/letsencrypt/options-ssl-apache.conf, to disable vulnerable SSLv2/v3 protocols.

On to the certbot process, download and run as super user:

curl -sS https://dl.eff.org/certbot-auto -o /usr/local/bin/certbot-auto
chmod +x /usr/local/bin/certbot-auto

/usr/local/bin/certbot-auto --apache certonly

I opted for the conservative approach of not allowing certbot to do any permanent Apache configuration changes and only acquire a certificate, by using the certonly option. This will do the verification process (using your running Apache server) and save certificates and account details under /etc/letsencrypt/. Note that certbot may ask to install additional packages on the system the first time you run it.

Certbot successfully detected the name based virtual host definitions in the Apache configuration (including aliases) and allowed me to choose for which domain names to acquire a certifcate. After selecting the domains, the validation process starts and, if successful, a certificate for the domains will be downloaded and made available on the system. This was an impressively simple process.

Configuring Apache on Ubuntu 14.04 to use Let’s Encrypt certificate

Assuming basic SSL support is enabled in Apache, the server runs with default options which come from /etc/apache2/mods-available/ssl.conf and [optionally] /etc/apache2/sites-available/default-ssl.conf. To SSL-enable an existing name based virtual host defined for port 80, I simply copied the defintion to a separate virtual host for port 443. Then I added the following configuration to the new virtual host definition:

<VirtualHost *:443>
  ServerAdmin webmaster@stegard.net
  ServerName  stegard.net
  ServerAlias www.stegard.net

  # Letsencrypt SSL options
  Include /etc/letsencrypt/options-ssl-apache.conf
  # virtual host cert
  SSLCertificateFile      /etc/letsencrypt/live/www.stegard.net/cert.pem
  SSLCertificateChainFile /etc/letsencrypt/live/www.stegard.net/chain.pem
  SSLCertificateKeyFile   /etc/letsencrypt/live/www.stegard.net/privkey.pem

[...]

Note to include the Let’s Encrypt recommended SSL options (have a look at the contents first), then specify the certificate files. This applies to Apache version < 2.4.8. If you are running Apache from -backports on Trusty, or on a newer Ubuntu, then you’ll have version  >= 2.4.10, which needs a slightly different certificate setup:

# Letsencrypt SSL options
Include /etc/letsencrypt/options-ssl-apache.conf
# virtual host cert
SSLCertificateFile      /etc/letsencrypt/live/www.stegard.net/fullchain.pem
SSLCertificateKeyFile   /etc/letsencrypt/live/www.stegard.net/privkey.pem

(The SSLCertificateChainFile directive is deprecated starting with Apache 2.4.8.)

This was the only setup required to get functional SSL for my site.

WordPress and https

My site runs WordPress where the primary site URL uses plain http. This is how I wanted SSL to work:

  1. Both https and http should work across the site.
  2. If site is accessed on https, then all [internal] links and included resources should use https as well. (Enter on https, stay on https.)
  3. Site administration is only available on https.

Number 1 was easy – this works out of the box if Apache is configured correctly. But I got mixed content warnings for various resources inluded in pages when accessing over https. When evaluating how to fix a certain annoyance in WordPress, I tend to look for the simplest solutions which do not require extra plugins first. So I fixed images and other things included in content to use relative URLs. But there were still theme specific resources included with plain http URLs, likely due to the site URL being plain http. Not wanting to spend very much time diagnosing such specific cases, I ended up installing the SSL Insecure Content Fixer plugin. I run this plugin in “simple” mode, which I assume does not have to post-process all content being served (which I really wanted to avoid). That was enough to get consistent https-links when accessing content over https, and so number 2 is considered solved.

Since WordPress has a built in config option to force admin over SSL, adding the following to wp-config.php resolved number 3 on my list of requirements:

/** Admin over SSL */
define('FORCE_SSL_ADMIN', true);

Validating https protocol support

Qualys SSL labs has what looks like a rather thorough online validator for SSL protocol support. I ran my site through this validator and got an A-rating, with no glaring deficiencies. To improve the rating even further, I could have used a stronger RSA key than the default of 2048 bits, but it is certainly good enough for now.

Automatic certificate renewal

Obviously I like to keep site maintenance cost as low as possible, and automating the renewal process of certificates is a must. Certbot makes this very easy as well. I simply created a script in /etc/cron.daily/certbot-renew with the following content:

#!/bin/sh
exec /usr/local/bin/certbot-auto renew --no-self-upgrade --quiet

Make sure it is executable, and then automatic renewal should be all set.

Donations to Let’s Encrypt and the way forward

My first experience with Let’s Encrypt has been great. I’ve spent much longer writing this blog post than the time it took to get the site up and running properly with https support. Good things deserve appreciation, especially when they are given away for free. I made a small donation to Let’s Encrypt for their excellent service.

I will switch my site to use SSL by default given some time. The cost of providing secure http by default has been reduced to something so neglible, I have few reasons not to.

Simple colored git branch status in Bash prompt

Update August 14: just pushed version 1.1 today. Less code, better performance and small bugs fixed – I always like this combo.

Original post:

I just rewrote some code I’ve been using for embedding git branch status in the Bash command prompt. It should be faster, more robust, cleaner and more compatible now. So I put it on Github: https://github.com/oyvindstegard/bashgit

If you use Bash and Git, give it a spin. It is intentionally kept simple in functionality, because the prompt is not my primary source of information about git repository status. I don’t want a long and cluttered prompt in general. It also tries to be as fast as possible, because no one likes a lagging command prompt.

Bashgit screenshot
Screenshot

New version of ds

I made some incremental improvements to my trusty synchronization tool. I have added ssh master connection sharing support, which should give a nice speed up in many cases. In addition to this, there are cleanups in auto completion code and more flexible command line parsing. There is a release on Github.

I do certain things the old fashioned way – synchronizing application config and data across different hosts is one of those areas. I don’t use Dropbox or other internet services for file sync purposes, except for the builtin Google stuff on my Android phone (which is mostly app config backup). I like to keep it peer-to-peer, simple and manual. And I like to keep my data private. Ds is just the right tool to make syncing that much easier, which I guess is the reason I wrote it.

Cloud services is not something I need to manage my data. I have my own “cloud services”: A synchronization scheme which works well enough, automated backups with regular encrypted offsite storage (a future blog post), personal web and file services and high speed fibre optic internet connection – all at home. I will admit to a certain level of NIH syndrome here, but my own solutions work well enough that I will not bother looking into something else yet.

Performance of stored field compression in Lucene 4.1+

Starting at version 4.1 of the Apache Lucene search library, compression of stored fields is enabled by default. The basic idea is that with some refinements to how compression is handled, disk I/O will often end up costing more time than the extra CPU cycles required to decompress data when retrieving documents from search results. This suits the most common usage scenarios of Lucene well, but is not always a win. Depending on factors such as server hardware and index update frequency, it may hurt performance if you have many small stored fields and/or your on disk index fits nicely in available OS cache memory in uncompressed form.

If you just need to know how to to disable stored field compression, you can skip directly to the solution.

Background

We use the Lucene heavily in our Java-based CMS solution. It’s mostly about indexing metadata, which is used for lookups and all kinds of listing queries. We gain flexibility and great speed by using Lucene instead querying the database through a SQL interface (the authoritive source of basically the same set of metadata that we index). Up to this point, things look pretty standard.

Our use of Lucene may be considered atypical, though. We do not index full text content (instead dedicated Apache Solr instances are used for that purpose), and we do not use scoring. Our metadata queries use pure boolean algebra and filters on typed data fields, and most use some defined sorting order (but never score). These queries are usually not based on human input, but rather pre-coded, configured or built dynamically by the system. Some searches will fetch a significant amount of documents from the result set, and also a significant amount of fields from each of those docs. In addition, we have lower level Lucene customizations like filters, callback based API for walking the index with no limits on number of retrievable matches and conversion of queries to filters for speed.

Migrating from Lucene 3 to 4 resulted in performance reduction

Last year, we did a major upgrade from Lucene 3.6.2 to Lucene 4.9. Testing had not revealed much difference in performance, but when it all went into production, we saw a noticeable increase in CPU usage on our application servers. Logs showed that searches took more time than with the previous Lucene 3 based release. (You may now argue that our performance testing was not thorough enough, and you would be right, but that is beside the point.)

After investigating thread dumps of busy JVMs, we discovered that many threads were often in Lucene code, and then in a decompresssing stage for stored field retrieval. This was consistently the case, and we figured it had to be the cause of the increase in CPU usage.

Solution: disable stored field compression

With many small stored fields that are often retrieved in search results and indices which fit in OS cache memory, compression yielded worse performance for us. Unfortunately there is no simple config option to adjust this feature in Lucene 4.X* and it requires swapping out a codec format class.
*I have not yet investigated if this is the case with Lucene 5.X.

You need to provide a custom codec class to your IndexWriter in order to disable stored field compression. There is a class called FilterCodec in the Lucene API which wraps a base codec class instance and delegates by default. It can be extended to allow overriding methods that provide specific parts or formats of a codec. In this case we need only change the stored fields format.

Create a custom codec class:

package org.foo.search;
import org.apache.lucene.codecs.FilterCodec;
import org.apache.lucene.codecs.StoredFieldsFormat;
import org.apache.lucene.codecs.lucene40.Lucene40StoredFieldsFormat;
import org.apache.lucene.codecs.lucene410.Lucene410Codec;

public final class Lucene410CodecWithNoFieldCompression extends FilterCodec {

    private final StoredFieldsFormat storedFieldsFormat;

    public Lucene410CodecWithNoFieldCompression() {
        super("Lucene410CodecWithNoFieldCompression", new Lucene410Codec());
        storedFieldsFormat = new Lucene40StoredFieldsFormat();
    }

    @Override
    public StoredFieldsFormat storedFieldsFormat() {
        return storedFieldsFormat;
    }
}

This custom  org.apache.lucene.codecs.Codec subclass uses Lucene410Codec as basis, but swaps out the stored fields format with Lucene40StoredFieldsFormat, which does not employ compression.

Set this codec class in your IndexWriterConfig instance:

IndexWriterConfig cfg = new IndexWriterConfig(Version.LATEST, someAnalyzer);
cfg.setCodec(new Lucene410CodecWithNoFieldCompression());

IndexWriter myWriter = new IndexWriter(someDirectory, cfg);

This takes care of the index writing part, and segments written by myWriter will not use compression for stored fields. However, Lucene also needs to be able to open and read index segments created by this writer, which in principle uses an entirely new custom codec. Lucene locates codec classes on the classpath through Java service provider interface (SPI) mechanism, where codecs are identified by name. Our custom codec uses the name "Lucene410CodecWithNoFieldCompression" (passed to the FilterCodec superclass constructor in the example class above).

Make the class available through SPI by creating a file:
META-INF/services/org.apache.lucene.codecs.Codec
with the following contents:

org.foo.search.Lucene410CodecWithNoFieldCompression

This file itself should be available in the classpath, e.g. in your appliaction jar or war file. Lucene will now be able to open and read index segments created by myWriter.

You should be aware that generic Lucene tools such as Luke will not be able to open indices created with your custom codec, since it is unknown to them. You can however provide the codec class by adding it their classpath, along with the SPI metadata file (assuming the tool is Java-based).

Difference in performance and size

We observed a clear reduction on server load average on our busiest site, and most queries have had their total execution time reduced. On the extreme side, some heavy data report queries that iterate many index documents had their total execution time reduced by up to 75%. We suspect this to be caused by access of small stored fields for many docs, which was hit pretty badly by compression. As for size, one of our larger indices grew by only 80% without compression, which is no problem for us.

Links

  1. Blog posts Efficient compressed stored fields with Lucene and Stored fields compression in Lucene 4.1 by Adrien Grand.
  2. https://issues.apache.org/jira/browse/LUCENE-4226
  3. https://issues.apache.org/jira/browse/LUCENE-4509
  4. https://issues.apache.org/jira/browse/LUCENE-5914

Distrowatching with Bittorrent

Updated ranking as of 25th of April:

  1. ubuntu-14.04.2-desktop-amd64.iso, ratio: 139
  2. ubuntu-14.04.2-desktop-i386.iso, ratio: 138
  3. ubuntu-14.10-desktop-i386.iso, ratio: 93.9
  4. ubuntu-14.10-desktop-amd64.iso, ratio: 87.0
  5. linuxmint-17.1-cinnamon-64bit.iso, ratio: 81.5
  6. debian-7.8.0-amd64-DVD-1.iso, ratio: 31.5
  7. Fedora-Live-Workstation-x86_64-21, ratio: 25.6
  8. debian-7.8.0-amd64-DVD-2.iso, ratio: 16.0
  9. debian-7.8.0-amd64-DVD-3.iso, ratio: 15.7
  10. Fedora-Live-Workstation-i686-21, ratio: 13.3
  11. debian-update-7.8.0-amd64-DVD-1.iso, ratio: 10.5
  12. debian-update-7.8.0-amd64-DVD-2.iso, ratio: 8.90

Total running time: 21 days, total uploaded: 1.04 terabytes.

Originally posted:

I have plenty of spare bandwidth at home, so I’ve been seeding a small selection of popular Linux ISOs via Bittorrent continuously for about 12 days now. Upload-cap was set to 1024 KB/s divided equally amongst all torrents (this is only about en eighth of my total uplink capacity).  Here are the results of the popularity contest as of now:

  1. ubuntu-14.04.2-desktop-amd64.iso, ratio: 93.3
  2. ubuntu-14.04.2-desktop-i386.iso, raitio: 83.5
  3. ubuntu-14.10-desktop-i386.iso, ratio: 57.1
  4. ubuntu-14.10-desktop-amd64.iso, ratio: 53.0
  5. linuxmint-17.1-cinnamon-64bit.iso, ratio: 46.1
  6. debian-7.8.0-amd64-DVD-1.iso, ratio: 18.3
  7. Fedora-Live-Workstation-x86_64-21, ratio: 15.6
  8. debian-7.8.0-amd64-DVD-3.iso, ratio: 10.1
  9. debian-7.8.0-amd64-DVD-2.iso, ratio: 9.48
  10. Fedora-Live-Workstation-i686-21, ratio: 7.82
  11. debian-update-7.8.0-amd64-DVD-2.iso, ratio: 6.13
  12. debian-update-7.8.0-amd64-DVD-1.iso, ratio: 6.06

A total of 636.0 GB has been uploaded. These are Transmission stats obtained at the time of writing this post. Though not statistically significant by any means, it is still interesting to note that Ubuntu seems more popular than Linux Mint on Bittorrent (contrary to what distrowatch.org has to say about it). Also, the LTS version of Ubuntu is more popular than the current 14.10 stable release. (I should add that the ratio of the Debian DVD ISOs cannot be directly compared, since these images are significantly larger in size. And Linux Mint MATE edition is not present at all.)

The list happens to be in accordance with my recommendation to anyone wanting to try Linux for the first time, specifically Ubuntu: go for the LTS version. (Recent Linux Mint is now also based on Ubuntu-LTS.) Many years of experience have taught me that the interim releases have a lot more bugs, annoyances and less polish. Sure, you learn a lot by fixing problems, but it’s perhaps not the best first time experience.

Game of Life in JavaScript

I recently had a period of time away from work to take care of my daughter at home. Of course, she would keep me busy most of the time, but being a computer enthusiast, I couldn’t resist a small side project to tinker with when otherwise idle.

My job mostly involves backend programming and architecture, so the obvious choice would be to do something entirely different. Also, the project needed to be small and manageable in size, so I could actually finish it. (My hobby computer projects tend to never truly end, but that’s another story.) There was little chance of getting any “zone time” programming done, since taking care of a small child demands much attention. So I decided to do an experiment with the HTML5 canvas element (specifically its 2D variant) and the JavaScript language. Both are rather easy to get into and easy to pick up whenever some time is available.

My canvas experiment is a “Game of Life” simulator-emulator-engine-thingy. Since the game of life is highly artificial with little resemblance to real life, it isn’t really simulating anything. Perhaps it’s emulating life at a “megascopic” scale of some sorts. At its core, it’s a game engine that draws cells, dead or alive, that evolve according to a set of simple rules. The frontend (page layout, input and controls) are separated. Code is JavaScript, of course. Should work across major modern browsers and mobile devices, though I haven’t really optimized it for touch input. It comes with a few interesting initial cell patterns and themes.

Anyway, here it is: Game of Life version 1-beta page. I doubt I’ll get much time to work with it in the coming months, but I plan to put it in my Github repo.

I’ll likely do a follow-up post later with some of my thoughts on the JavaScript language before and now, and standardization across browser implementations.

New site

New

New pages. All modern and with less contrast, so things are slightly harder to read. I just blame the design crowd, in general. Use the top menu to navigate pages – most of the old content is still available. Some of the less maintained things have been removed completely though.

Code (formler know has “Tools and hacks”) here. If you wonder who I am, look here.
